NISE 3910E-A Series
NISE 3910E-A Series - Image 2

For further information and inquiries, please reach out to us.

  • High-performance edge computing & industrial automation with i9/i7 CPUs.
  • Balanced general-purpose IoT and automation tasks with i5 CPUs.
  • Low-power monitoring and lightweight control with i3 CPUs.
  • Supports multi-display outputs (HDMI, DP, VGA) for visual monitoring and control.
  • Rugged, fanless design with wide DC input (+12–30V) and extended temperature range (-20°C to 60°C).
Categories: , , Brand:

Description

Further information

Data Sheet



Integrated with 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 processor, NISE 3910E-A is the fanless PC designed for industrial automation and edge computing which demand high CPU and graphics performance. NISE 3910E-A supports up to 64G DDR5 memory and have several options on storage devices like M.2, HDD or SSD. NISE 3910E-A supports wide range of DC input from +12V to 30V DC input, and can be operated in an extended temperature range between -20 to 60 Celsius degree. For extended module availability, NISE 3910E-A is also equipped with one internal mini-PCIe sockets to support IoT wireless connectivity applications (support optional Wi-Fi, 3.5G, 4G LTE modules), also 5G module via M.2 3052 Key B.

Additional information

CPU Architecture

Intel Core Ultra, Intel Raptor Lake-U, Intel Alder, Intel Core
CPU Cores

4 Core, 6 Core, 8 Core, 12 Core, 16 Core
Features

COM Ports RS-232 / RS-485, fanless, GPIO
Grade

Industrial, Semi-Industrial
Memory

RAM 8GB, RAM 16GB, RAM 32GB, RAM 64GB
