Description
|
If COM is…
|
AND LAN is…
|
The resulting model is:
|
Disk Support
|
|---|---|---|---|
|
4 Ports
|
2 Ports
|
EBOX-RTL-1335U (Base)
|
M.2 NVMe
|
|
6 Ports
|
2 Ports
|
EBOX-RTL-1335U-C6
|
SATA III (2.5″)
|
|
8 Ports
|
2 Ports
|
EBOX-RTL-1335U-MUX8
|
SATA III (2.5″)
|
|
4 Ports
|
3 Ports
|
EBOX-RTL-1335U-L3
|
SATA III (2.5″)
|
|
4 Ports
|
4 Ports
|
EBOX-RTL-1335U-L4
|
SATA III (2.5″)
|
Further information
Data Sheet
High-performance embedded computer powered by 13th Gen Intel® Core™ i5-1335U processor, delivering up to 4.6GHz computing power. Supports dual-channel DDR5 4800MHz memory up to 64GB for enhanced bandwidth.
Offers multiple display outputs—HDMI, DP, and USB Type-C DP—supporting up to four simultaneous 4K HDR displays. Equipped with rich I/O including 2.5GbE LAN, RS232/422/485, SATA III, GPIO, and versatile M.2 slots with Nano SIM support. Designed for industrial applications with wide voltage input (12~36V) and operating temperature range of -20°C to +50°C.
